Rizonflow®RFP High Flow Filter Cartridge
Retail price
0.0
元
Market price
0.0
元
Number of views:
1000
Product serial number
Category
Filter Cartridge Series
Quantity
-
+
Stock:
0
产品描述
Parameters
Rizonflow®RFP series high flow filter cartridge combines innovative technology and advanced design. With a large diameter of 6 inches, the maximum flow rate of a single filter can be up to 300gpm/70m3/h, reducing the number of filters, greatly reducing the diameter of the filter shell and saving floor space.
The filter material uses high quality polypropylene, suitable for water-based or non-water-based fluid, more uniform distribution, especially in the field of food and beverage direct contact with food, has excellent performance. Folding structure, effectively increase the filter area of a single filter element, enhance the capacity to absorb pollution.
Patented guide layer design guides the longitudinal distribution of water, accelerates the filtration of water by the filter element, and avoids the blockage caused by concentrated filtration of water by the filter element. The water inlet is provided with a water baffle to alleviate the impact of water, make the water evenly distributed, effectively protect the filter element, and make the filtration performance stable and reliable. High strength support frame design, effectively resist water pressure, prevent deformation of filter element, prolong service life.
O-ring design and top handle design more perfect seal, replacement without special tools, shorten downtime, simple installation, save labor costs.
The filter material uses high quality polypropylene, suitable for water-based or non-water-based fluid, more uniform distribution, especially in the field of food and beverage direct contact with food, has excellent performance. Folding structure, effectively increase the filter area of a single filter element, enhance the capacity to absorb pollution.
Patented guide layer design guides the longitudinal distribution of water, accelerates the filtration of water by the filter element, and avoids the blockage caused by concentrated filtration of water by the filter element. The water inlet is provided with a water baffle to alleviate the impact of water, make the water evenly distributed, effectively protect the filter element, and make the filtration performance stable and reliable. High strength support frame design, effectively resist water pressure, prevent deformation of filter element, prolong service life.
O-ring design and top handle design more perfect seal, replacement without special tools, shorten downtime, simple installation, save labor costs.
Product features
- Large diameter, high flow rate
- Patented design of diversion layer to avoid blocking of filter element
- Folding design increases filtration area
- High quality filter material, more uniform distribution
- Not easy to deform, long service life
- Small footprint and low investment cost
- Special support network fixed, stable operation
- A wide range of length and accuracy grades to choose from
- Safe and environmentally friendly, easy to dispose of
- Material meets FDA standard
- ISO9001 quality system certification
Application field
flow meter
- Reverse osmosis backwash filtration
- Reverse osmosis security filtering
- Ultrafiltration cleaning/backwashing filtration
- Wastewater treatment
- Coal chemical industry
- Electric power
- petrochemical
- Iron and steel
- electronic
- Food and beverage
- Medicine (Process water)
- petrochemical
Technical parameters
Filter system comparison
| The parameter types | The parameter value |
| Precision grade |
0.5，1，5，10，70μm |
| Outer diameter |
6inch |
| The inner diameter |
3.5inch |
| The length of the |
40inch 60inch |
| Filter material | polypropylene |
| Support the skeleton | polypropylene |
| Support layer | Polypropylene + glass fiber |
| Support layer | polypropylene |
| Seal ring/O ring | epdm |
| The highest temperature |
180ºF / 82ºC |
| The maximum flux |
300gpm / 70m3 / h |
| It is recommended to replace the differential pressure |
35psid / 2.5bard |
| Maximum operating differential pressure |
50psid@180ºF / 3.4bard@82ºC |
Filter characteristics
| Model | Precision | Effective filtration efficiency | The flow factor | ||||
|
90% |
95% |
98% |
99% |
99.9% |
|||
|
RFP005 |
0.5 |
0.5 |
1 |
2 |
5 |
10 |
0.003 |
|
RFP010 |
1 |
1 |
3 |
7 |
10 |
30 |
0.0007 |
|
RFP050 |
5 |
5 |
10 |
20 |
30 |
50 |
0.0004 |
|
RFP100 |
10 |
10 |
30 |
50 |
60 |
90 |
0.0003 |
|
RFP700 |
70 |
70 |
80 |
100 |
130 |
150 |
0.0001 |
| Note: the flow factor 【psid/gpm】is 40 inch | |||||||
Styling Instructions
| Code |
Description |
Parameter |
|
RF |
Filter element |
|
|
P |
filter material |
P = polypropylene |
|
050 |
filter precision |
005 = 0.5μm 010 = 1μm 050 = 5μm 100 = 10μm 700 = 70μm |
|
40 |
filter element length |
40 = 40inch 60 = 60inch |
|
N |
Filter precision |
N = nominal accuracy |
|
P |
support frame material |
P = Polypropylene |
|
X-L |
product code |
|
